Pneumatic Valve Control is an Open and Shut Case – Pun Intended

by | Feb 26, 2020 | Valve Manufacturer

Valves are to hydraulic controlled air systems what doors are to any proper establishment. The opening, closing, and the rate thereof separates one fluid power circuit from another. Picture a building without doors; it doesn’t make much sense. So it is with industrial flow. To simplify the matter, a pneumatic toggle valve, a featured staple part, ultimately determines the direction of pressure. And just like doors have knobs, this specific apparatus has a switch – which is sometimes manual or automatic depending on objective design.

Control Types: From Manual to Solenoid

Quality manual actuators require engineered operations…pretty straightforward. By contrast, the solenoid unit helps translate corresponding electrical signals. In many organizations today, automatic sequencing guides controls from a remote location. These come in two forms, namely direct or pilot managed.

Think of direct and pilot like direct current versus an alternating current. The direct pneumatic toggle valve sends the signal to the central unit and the valve acts accordingly. A pilot operating relief arrangement contains a bleed orifice and depends heavily on line pressure as a catalyst. In this case, the solenoid instructs the core to displace energy from the piston to the outlet. No signal from the solenoid is the stop gap.

Single Solenoid System

As the name suggests, one solenoid shifts valve spools. Without the electrical transmission, the spring force moves things back to normal. Currents is a dominating force when it comes to input, especially in the framework of fluid based indicator processes.
